The Xiaomi 17 Pro Max boasts a stunning 6.9-inch LTPO AMOLED display with a 120 Hz refresh rate and peak brightness of 3,500 nits, offering ultra-smooth and vivid visuals.
It runs on the Snapdragon 8 Gen 5 chipset built on a 3 nm process, paired with up to 16 GB of RAM and 1 TB of UFS 4.0 storage for exceptional speed and efficiency.
The triple 50 MP camera system includes a main wide sensor, an ultra-wide lens, and a 5× periscope telephoto for detailed zoom shots and professional-level photography.
A massive 7,500 mAh battery powers the phone, supporting 100 W wired, 50 W wireless, and 22.5 W reverse wireless charging for reliable all-day use and quick top-ups.
With its 8 mm slim glass-and-metal design, IP68 water resistance, and refined premium finish, the Xiaomi 17 Pro Max combines elegance, strength, and flagship quality.
Network
Technology
GSM / HSPA / LTE / 5G
2G bands
GSM 850 / 900 / 1800 / 1900
3G bands
HSDPA 800 / 850 / 900 / 1700(AWS) / 1900 / 2100
4G bands
1, 2, 3, 4, 5, 7, 8, 12, 13, 17, 18, 19, 20, 25, 26, 28, 34, 38, 39, 40, 41, 42, 48, 66, 71
5G bands
1, 2, 3, 5, 7, 8, 12, 13, 18, 20, 25, 26, 28, 38, 40, 41, 48, 66, 70, 71, 77, 78, 79, 80, 81, 83, 84, 89 SA/NSA
Launch
Announced
2025, September 25
Status
Available. Released 2025, September 25
Body
Dimensions
162.9 x 77.6 x 8 mm (6.41 x 3.06 x 0.31 in)
Build
Glass front (Dragon Crystal Glass 3), aluminum frame
IP68 dust tight and water resistant (immersible up to 6m for 30 min)
Display
Type
LTPO AMOLED, 68B colors, 2160Hz PWM, 120Hz, Dolby Vision, HDR Vivid, HDR10+, 3500 nits (peak)
Size
6.9 inches, 116.6 cm2 (~92.3% screen-to-body ratio)
Resolution
1200 x 2608 pixels, 19.5:9 ratio (~416 ppi density)
Protection
Xiaomi Dragon Crystal Glass 3
Secondary display (on the back):
LTPO AMOLED, 120Hz, Dolby Vision, HDR Vivid, HDR10+, 3500 nits (peak)
2.9 inches, 596 x 976 pixels
Platform
Chipset
Qualcomm SM8850-AC Snapdragon 8 Elite Gen 5 (3 nm)
CPU
Octa-core (2×4.6 GHz Oryon V3 Phoenix L + 6×3.62 GHz Oryon V3 Phoenix M)
Memory
Internal
512GB 12GB RAM, 512GB 16GB RAM, 1TB 16GB RAM
Main Camera
Triple
50 MP, f/1.7, 23mm (wide), 1/1.28″, 1.22µm, dual pixel PDAF, OIS
50 MP, f/2.6, 115mm (periscope telephoto), 1/1.95″, 0.8µm, PDAF (30cm – ∞), OIS, 5x optical zoom
50 MP, f/2.4, 17mm, 102˚ (ultrawide), 1/2.88″, 0.61µm, PDAF
Features
Laser AF, color spectrum sensor, Leica lens, Dual-LED dual-tone flash, HDR, panorama
Video
8K@30fps (HDR), 4K@30/60/120fps (HDR10+, 10-bit Dolby Vision HDR, 10-bit LOG), 1080p@30/60/120/240/960fps, 720p@1920fps, gyro-EIS
Selfie camera
Single
50 MP, f/2.2, 21mm (wide), 1/2.88″, 0.61µm, PDAF
Video
4K@30/60fps, 1080p@30/60fps, HDR10+, gyro-EIS
Sound
Loudspeaker
Yes, with stereo speakers (with Dolby Atmos)
24-bit/192kHz Hi-Res & Hi-Res wireless audio
Snapdragon sound
Comms
WLAN
Wi-Fi 802.11 a/b/g/n/ac/6e/7, dual-band, Wi-Fi Direct
Bluetooth
5.4, A2DP, LE, aptX HD, aptX Adaptive, LHDC 5
Positioning
GPS (L1+L5), BDS (B1I+B1c+B2a), GALILEO (E1+E5a), QZSS (L1+L5), NavIC (L5), GLONASS
USB
USB Type-C 3.2, Display Port, OTG
Features
Sensors
Fingerprint (under display, ultrasonic), accelerometer, proximity, gyro, compass, barometer
Ultra Wideband (UWB) support
Battery
Charging
100W wired, PD3.0, QC3+, 100W PPS
50W wireless
22.5W reverse wireless
Misc
Colors
Black, White, Purple, Green
Our Tests
Performance
AnTuTu: 2456317 (v10), 3543388 (v11)
GeekBench: 10600 (v6)
3DMark: 6761 (Wild Life Extreme)
Display
1026 nits max brightness (measured)
Loudspeaker
-26.1 LUFS (Good)
